DURKOPP ADLER 867 Instruction Manual

5.1 Technical data subclasses
Subclasses
867-160152 867-190020 867-190040 867-190122 867 190125 867-190142 867-190145 867-190146 867-190322 867-190342
Type of stitch Lockstitch 301
Hook type
small large oversized large large oversized oversized oversized large oversized
Numberofneedles 1111111111
Needle system 134-35
Needle size 180
(depending on E-No.) [Nm]
Max. thread thickness [Nm] 80/3 - 10/3
Stitch length [mm]
- Forward 12
- Backward 12
Numberadj.stitchlengths 1111112222
Max. number of stitches [ min
-1
] 4000 3200 3800 3800 3400 3400 3800 3800 3400 3800
Number of stitches with
factory setting [min
-1
] 3400 3000 3400 3400 3400 3400 3400 3400 3400 3400
Max. lifting height [mm] 20 20 20 20 20 20* 20* 20* 20* 20*
(*only with tur n-back device)
Max.sewingfootstroke [mm]9999999999
Operatingpressure [bar]-666666666
Air consumption per
working cycle [NL] - 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7
Dimensions (L x W x H) [mm] 690 / 220 / 460
Weight 55 55 55 55 55 55 55 55 55 55
with direct drive [kg] - 59 59 59 59 59 59 59 59 59
26
Keystone Sewing Machine Company, Inc.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
