DURKOPP ADLER 867 Instruction Manual

6.7 Changing the hook-thread bobbin
Caution: danger of injury !
Tur n off t he main switch.
The hook-thread bobbin may only be changed with the machine
switched off.
Remove the empty bobbin
–
Raise up the flap 1 and remove the empty bobbin.
Insert a full bobbin
–
Insert the bobbin 2 so that it moves in the opposite direction of the
hook when unwinding.
–
Conduct the hook thread through the slot 3 and underneath the
spring 4.
–
Pull the hook thread through the slot 6 and continue pulling until it
stands out about 3 cm.
–
Close the flap 1 and pull the hook thread through the thread
guiding 5 of the flap.
44
654
1
2
3
Keystone Sewing Machine Company, Inc.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
