DURKOPP ADLER 867 Instruction Manual

9 Sewing
Operating and function sequence:
Sewing process Operation / explanation
Prior to sewing
Starting position
Position material correctly
for starting the seam.
- Pedal in rest position
The machine is at a halt.
Needle up, sewing feet down.
- Pull pedal half-way back.
The sewing feet are raised.
- Push material forward until it touches the needle.
Sewing
- Push pedal forwards and keep it pushed.
Subsequently the machine will continue sewing with the
rotation speed determined by the pedal.
In mid-seam
Interrupt the sewing process
Resume the sewing process
(after releasing the pedal)
- Release pedal (rest position).
The machine halts in the 1
st
position.
The sewing feet are down.
- Push pedal forwards.
The machine sews at the speed of rotation set by
the pedal.
63
GB
6
54 3 2 1
Keystone Sewing Machine Company, Inc.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
