2.8 Adjusting the reduced stitch length
Note: It is an optional equipment.
Rule:
If a reduced stitch is selected via a switch button, it should then be
effectively 50% with 7 mm stitch length and between 60% and 70%
with 2 mm stitch length.
–
Loosen nut (1).
–
Shift the piece (4) through changing the position of the screw (3)
with a 2.5 mm Allen key (2) until the stitch length corresponds to
the value given in the above rule.
–
Fasten nut (1).
Caution: Risk of injury!
Turnthemainswitchoff.
Only carry out this adjustment when the machine is turned off.
15
EN
321 4
