EN-204 User and Installation Guide
64
Do one of the following:
If your mail server requires authentication to login, check
Authentication.
a. In the User Name text box, enter the user name assigned in the mail
server.
b. In the Password text box, enter the password assigned in the mail
server.
c. In the Confirm text box, re-enter the password.
If your mail server does not require authentication to login, skip to
Step 3.
Configure the following Email settings:
SMTP Server – Enter the SMTP Server IP address or host name (e.g.,
smtp.yourmail.com).
SMTP Port – The SMTP port number. The default TCP/IP port used for
SMTP is 25.
Enable SSL – Select the checkbox to enable SSL if it is required by the
SMTP server. The default TCP/IP port used for SMTP is 465.
Interval – Enter the interval of the number of seconds between two
instances of sending picture attachments.
Attached Image – Select this checkbox if you want to send email with
attached alarm images.
Sender – Enter the name of the sender.
Sender’s Address – Enter the Email address of the sender.
Choose Receiver – Select the receiver to whom the Email is sent. Up to
three receivers can be configured.
Receiver – Enter the name of user to be notified for receipt of the
Email.
Receiver’s Address – Enter the Email address of user to be notified.
Click Save to save the Email settings.
5.4.4.4 SNMP
The SNMP screen is used to configure settings so that the encoder can be managed by an Internet
Protocol (IP)-based management system. The Simple Network Management Protocol (SNMP)
provides camera status, device parameter and alarm-related information.
Before configuring SNMP settings, make sure that:
1. You have an SNMP manager application.
2. The SNMP versions you select on the encoder is supported by the SNMP manager.
