EN-204 User and Installation Guide
84
In the Trigger Channel area, do one of the following when an event occurs:
 Check Select All to trigger recording on all cameras.
 Select a camera checkbox to trigger recording on the selected cameras.
Do one of the following:
 If you are using a fixed camera, skip to the next section.
 If you are using a PTZ camera, go to the next step.
If you are using a PTZ camera, in the PTZ Control area, do the following:
From the PTZ Control drop-down list, select a camera (channel).
To enable a Preset, check Enable. The Preset No. drop-down list is enabled.
 From the Preset No. drop-down list, select a preset number from 1-265.
Note:
A Preset is a predefined camera view that is composed of the camera's
pan, tilt, and zoom settings. Each preset is numbered and enables an
operator to quickly jump to that specific position in a live view.
To enable a Sequence, check Enable. The Sequence No. drop-down list is enabled.
 From the Sequence No. drop-down list, select a number from 1-16.
Note:
A Sequence is an automated series of camera movements from one
Preset to another, in a pre-determined order, and for configurable
time periods.
To enable a Pattern, check Enable. The Pattern No. drop-down list is enabled.
 From the Pattern No. drop-down list, select a number from 1-6.
Note:
A Pattern is a stored route defined through manual adjustment of pan,
tilt, and zoom.
Repeat Steps a-d for each camera.
Go to the next section.
To copy alarm settings to another camera
In the Copy to Alarm area, do one of the following:
 Check Select All to copy the alarm settings to all alarms.
 Check an alarm checkbox to copy the alarm settings to that specific alarm.
Click Save.
