Dwin T5L ASIC Series User Manual

T5L_ASIC Development Guide
- 9 -
www.dwin-global.com
D WI N T echnology
Pro f essional , Credi t able , Success f ul
GUI
102
P5.3
I/O port
LCD_G3
LCD interface
GUI
103
P5.4
I/O port
LCD_G4
LCD interface
GUI
104
P5.5
I/O port
LCD_G5
LCD interface
GUI
105
P5.6
I/O port
LCD_G6
LCD interface
GUI
106
P5.7
I/O port
LCD_G7
LCD interface
GUI
107
VDD
T5L1=1.25V
T5L2=1.2V
GUI
108
VIO
3.3V
GUI
109
P6.0
I/O port
LCD_R0
LCD interface
GUI
110
P6.1
I/O port
LCD_R1
LCD interface
GUI
111
P6.2
I/O port
LCD_R2
LCD interface
GUI
112
P6.3
I/O port
LCD_R3
LCD interface
GUI
113
P6.4
I/O port
LCD_R4
LCD interface
GUI
114
P6.5
I/O port
LCD_R5
LCD interface
GUI
115
P6.6
I/O port
LCD_R6
LCD interface
GUI
116
P6.7
I/O port
LCD_R7
LCD interface
GUI
117
VDD
T5L1=1.25V
T5L2=1.2V
GUI
118
VIO
3.3V
Note that the pads on the bottom of the IC must be reliably grounded, otherwise the performance of the
IC will be affected.

Dwin T5L ASIC Series Specifications

General

Brand	Dwin
Model	T5L ASIC Series
Category	Control Unit
Language	English
