UFM2/UBT User Manual
Page 18 Issue 1.1b July 20
2.10 Normal Operation
The screen sequence is different for the UFM2 and UBT models.
2.10.1 UFM2
Press .
The unit checks for a valid flow signal.
If a valid signal is found, signal strength and flow rate
are displayed. The signal strength should be at least
40% for reliable operation.
2.10.2 UBT
Press .
The unit checks for a valid flow signal.
If a valid signal is found, signal strength and flow rate
are displayed. The signal strength should be at least
40% for reliable operation.
Press the and keys to scroll to the Total Flow, Temperature dT, Total Energy and
Instant Power screens.
Checking Signals
Searching...
Sig:80% *
120.00 USgal/m
Checking Signals
Searching...
Sig:98% *
0247.8 USgal/m
Instant Power:
617.00 BTU/s
Temperature dT
H53.9 C17.4:36.5
Total Energy:
50.09 kBTU
Total Flow:
598.7 USgal
