Dwyer Instruments UFM2 - Temperature Sensor Probes (UBT Only)

UFM2/UBT User Manual
Page 10 Issue 1.1b July 20
2.2.5 Temperature Sensor Probes (UBT only)
Two separate 4-core plug-in cables are provided for the Temperature Sensor Probes connections.
These plug into the right-hand side of the Electronics Module.
Figure 10 UBT Temperature Probe Wiring
UBT
COLD
HOT
White
White
Red
Red
White
White
Red
Red
4
3
1
2
Solder pin side
