Cable For SCN5 Actuators (RP9100-XXX)
Cable For All Actuators Other Than SCN5
I/O cable to connect with PLC
and/or switches
(
Thicker cable
)
Power connection cable
(Thinner cable)
Connect to
Mechatronics Cylinder
Signal cable to connect with
PLC and/or switches
(Thicker cable)
Power connection cable
(Thinner cable)
Connect to the power & I/O connection of the actuator or controller
