Dyadic Systems SCN6 - SCN6;SCLT;SCLL Output Signals and Details

. .
Dyadic Systems – Mechatronics Cylinder Manual MF-005500-EN-50/63
No.
Symbol Functions
15 PM1 Completion signal output: Total of PM1 to PM8
ON means 1, OFF means 0
16 PM2 Completion signal output: Total of PM1 to PM8
ON means 2, OFF means 0
17 PM4 Completion signal output: Total of PM1 to PM8
ON means 4, OFF means 0
18 PM8 Completion signal output: Total of PM1 to PM8
ON means 8, OFF means 0
19 PFIN Position completion output
① ON: The output goes high when the Mechatronics Cylinder has moved to within the
position width tolerance of the target position. Please note that PFIN signal won’t be
turned ON till CSTR signal is turned OFF.
② OFF: The output goes low when motion to a new target position is initiated.
Notes:
-The tolerance used to determine when the PFIN output goes high is set by the “At
Position Width” variable in the programming device.
-This output will not operate properly if the “CSTR” signal is left high. The CSTR signal
should be pulsed OFF-ON-OFF to initiate motion, and therefore is expected to be OFF
when motion finishes.
20 ZFIN Homing completion output
① ON: The output will be ON after homing completion.
② OFF: The output is OFF after the Mechatronics Cylinder is first powered up and /or
when an encoder-related alarm occurs. ZFIN won’t be turned ON until the homing is
completed.
21 ZONE Zone signal output
① ON: The output will be ON when the position of the axis is within the range
programmed to be the “Zone”.
② OFF: The output will be OFF if the axis has not been homed or if the rod is outside the
programmed zone.
22 ALM Controller alarm output
① ON: The output will be ON during normal operation.
② OFF: The output will be OFF in case of Alarm occurs.
23 NC No connection
24 FG Frame Ground
6.2.4. Output signal details
[PFIN]
This is the position completion signal.
The output first goes high after the power supply is turned ON and the servo amplifier is ready for operation.
The PFIN signal will be turned OFF when the CSTR signal is turned ON to command a move. PFIN will be
turned back ON when the current actuator position is within the range of the “At Position Width” parameter
(set in the programming package) from the programmed destination position if the CSTR signal has been
turned OFF.
The PFIN signal will also be turned OFF if the actuator is beyond the software stroke limit.
