Dyadic Systems SCN6 - Page 28

. .
Dyadic Systems – Mechatronics Cylinder Manual MF-005500-EN-28/63
Connection of Serial Interface (SIO Connection)
+24V
FG
PC1
PC2
PC4
PC8
0V
CSTR
ILK
PFIN/INP
ALM
ZONE
ZFIN
TRx+
TRx-
+5V
0V
(Program desired stop position)
+
24V
Power Shut Down Order
Please ground at
ground resistance
100ohm or smaller
To RS
-
232C
Serial (COM) Port
RS
-
232C/RS
-
485
Converter
SIO Cable
A
DP Cable
Connector Converter
SCN5 Model (10Kgf Type)
SCN6 PNP Models / SCLL PNP Models
SCL
T
PNP Mode
l
(
Externa
l
Am
p
T
yp
e
)
