Dyadic Systems SCN6 - SCN6 Model Specifications

. .
Dyadic Systems – Mechatronics Cylinder Manual MF-005500-EN-31/63
SCN
6
Models
(
20K
g
f, 40k
g
f, 50k
gf
& 60k
gf
T
y
pes
)
MODEL
SCN6-020 SCN6-040 SCN6-050 SCN6-060
050 100 150 200 250 300 050 100 150 200 250 300
050 100 150 200 250 300 050 100 150 200 250 300
Stroke (mm) 50 100 150 200 250 300 50 100 150 200 250 300 50 100 150 200 250 300 50 100 150 200 250 300
Life Other than seal 3 years after the delivery, or 10,000 km operation under the use within the specs.
Seals 6 months, or 2,500 km run (Dust Proof Model Only)
Max. Thrust (N) / (kgf) 200 / 20.2 400 /40.8 500 / 51.0 650 /66.3
Max. vertical carriable wt at power ON 14 28 30 45
Push mode max. Thrust (N)/(kgf) 140 / 14.2 280 / 28.5 350 / 35.5 450 / 45.9
Max. Speed (mm/s) * note 1 200 100 100 100
Repeatability (mm) ±0.1
Backlash (mm) 0.3
Radial Load Capacity (N) 30 20 10 10 10 10 30 20 10 10 10 10 75 50 25 18 15 12 75 50 25 18 15 12
Rod Diameter (mm) Ø22
Rod Tip Thread
M14 Pitch 1.5 (303SS)
Program Capacity 16 Motions
Power Supply DC24V ± 10% (Drive Power max. 3.0 Amps, Control power max. 0.2A)
Parallel DC24V type DI/DO Interface (Connector PIO)
Input Names Position number (4 bit binary: PC1,PC2,PC4,PC8)
Start (CSTR), Axis Movement Interlock (ILK)
Input current
Max. 4mA / port
I/O Parallel DC24V type DI/DO Interface (Connector PIO), Position complete(PFIN/INP),
Output Names Completed Position Number (4bit binary: PM1,PM2,PM4,PM8),
Homed signal(ZFIN), Zone signal(ZONE), Alarm (ALM)
Output current
Max. 10mA / port
Serial Signal Serial Interface (Connector SIO) +5V, 0V, S+, S-
Protection function Over speed, Main power over voltage, abnormal voltage,
Overload, Sensor abnormal, Servo abnormal, Encoder wire disconnected
Operate Temperature 0 ~ 40°C
Ambience Storage Temperature -20 ~ 60°C
Ope/Storage Humidity ≤ 90% RH, non-condensing
Vib./shock Duravility 2G/10 times
Protection IP-40 equivalent (Standard), IP-54 (Dust proof sealed model)
Weight (kgs) 1.6 1.9 2.2 2.5 2.8 3.1 1.9 2.2 2.5 2.8 3.1 3.4 1.9 2.2 2.5 2.8 3.1 3.4 1.9 2.2 2.5 2.8 3.1 3.4
Functions - Positioning with speed, Accele - Increment movement - Stroke Limit end set - Zone Signal output - Push Force Mode
- Home Direction Set - Suitable Auto Max. Accel - Zone Signal output - Complete signal range set - Servo Gain Adjust
Notes: (*1) Typical data (*2) Stroke 200mm, 250mm and 300mm are available.
