Dyadic Systems – Mechatronics Cylinder Manual MF-005500-EN-33/63
MODEL
SCLL6- SCLL6- SCLL6- SCLL6- SCLL6- SCLL6- SCLL6- SCLL6-
020-300A 020-400A
020-500A
020-600A
020-700A 020-800A 020-900A
020-A00A
Stroke (mm) 300 400 500 600 700 800 900 1000
Max. Thrust (N) / (kgf) 200 / 20.4
Max. vertical carriable wt at power ON 2.5 kgs
Push mode max. Thrust (N)/(kgf) 140 / 14.2
Max. Speed (mm/s) * note 1 300 280 220 180 150
Repeatability (mm) ± 0.1
Backlash (mm) 0.3
Max. Load weight (kgs) 5 2 1
Max. vertical load (kgs) 2.5 2 1
Load moment (kgf-m) Mp=0.5, My=0.5, Mr=0.5 Mp=0.3, My=0.3, Mr=0.3 Mp=0.2, My=0.2, Mr=0.2
Overhang length (mm) 150 or shorter
Program Capacity 16 Positionings
Power Supply DC24V ± 10% (Drive Power max. 3.0 Amps, Control power max. 0.2A)
Life 3 years after the delivery, or 10,000 km operation under the use within the specs.
Parallel DC24V type DI/DO Interface (Connector PIO)
Input Names Position number (4 bit binary: PC1,PC2,PC4,PC8)
Start (CSTR), Axis Movement Interlock (ILK)
Input current
Max. 4mA / port
I/O Parallel DC24V type DI/DO Interface (Connector PIO)
Output Names Completed Position Number (4bit binary: PM1,PM2,PM4,PM8), Positioning complete(PFIN/INP),
Homed signal(ZFIN), Zone signal(ZONE), Alarm (ALM)
Output current
Max. 10mA / port
Serial Signal Serial Interface (Connector SIO)
+5V, 0V, S+, S-
Protection function Over speed, Main power over voltage, abnormal voltage,
Overload, Sensor abnormal, Servo abnormal, Encoder wire disconnected
Ambience Operate Temperature 0 ~ 40°C
Storage Temperature -20 ~ 60°C
Ope/Storage Humidity ≤ 90% RH, not dew on the products
Weight (kgs) Actuator 3.7 4.7 5.7 6.7 7.7 8.7 9.7 10.7
Amplifier 0.5
Functions Positioning with speed, Accele/Decel Servo Gain Adjust
Push Force Mode Stroke Limit end set
Home Direction Set Zone Signal output
Speed Profile
Suitable Auto Max. Accel
Notes: (*1) Typical data, (*2) Rodless Actuators with stroke of 600 ~ 1,000mm are not stock items. Please call for delivery.
SCLL
Mode
Slider 20K
T
pe
