Maintenance Manual (960-945)
4-43
Replacement Procedures
Figure 4-48 Removing the camera module (
1)
2.
Disconnect the camera FPC from the connector on the camera mo
dule
and peel off the FPC
from the LCD cover
.
Figure 4-49 Removing the camera module (
2)
3.
Peel off the
camera module
from the LCD cover
.
Figure 4-50 Removing the camera module (
3)
1
2
Camera module
118
120
