13CA 150 M150EN2
Fig. 10 Control panel
1. Reserve-/parking brake knob
2. Forward/reverse lever
3. Warning lamp
1
3
2
EVERY 10 OPERATING HOURS (Daily)
Check operation of the brakes as follows:
Drive the roller slowly forward.
Push the reserve/parking brake knob (1); the warning
lamp (3) on the instrument panel should light and the
roller should stop.
After testing the brakes, set the forward/reverse lever
(2) in neutral.
Pull up the reserve-/parking brake knob.
The roller is now ready for operation.
WARNING
Brake function – Check
