Product Composition
 System Composition: The energy storage system of this product mainly includes battery
module, BMS, PCS, MPPT (optional), STS (optional), power distribution system, fire
protection system, air-conditioning system and so on.
Table 3-1 Product composition
Module Name
functionality
Module Selection
battery module
For electrical energy storage
compulsory
BMS module
Collect battery information and control battery
charging and discharging
compulsory
MPPT Module
Maximizing PV power
1-3 (optional)
PCS module
AC and DC bi-directional conversion
compulsory
STS module
Automatic fast switching between on-grid and
off-grid
1（optional）
EMS Module
Energy management and total control of the
entire system
compulsory
power
distribution
system
Includes circuit breakers, wiring harnesses, fuses,
etc.
compulsory
fire protection
system
Timely warning of battery thermal runaway
characteristics and making correct instructions
compulsory
air conditioning
system
Regulates the battery operating temperature to
ensure that the battery operates at the optimal
temperature
compulsory
The system is designed with many functions, and users can select and configure
accessories based on their actual needs to achieve different purposes. The table of
optional accessories is as follows:
Table 3-2 Optional accessories list
Optional
Accessories
Optional quantity
Functional Description
STS Module
1
200kW with automatic switching
between on-grid and off-grid
MPPT Module
1-3
Transmits the energy generated by
the PV panels to the system
HMI screen
1
User interface
Users can independently choose optional accessories for this product based on power
requirements, whether to install PV systems, on-grid/off-grid demands and etc. By
combining different modules, the different models can be configured as follows:
