MPPT Power
50kW per channel
System specification parameters: (Applicable to all models)
Dimension (W*D*H)
1.85*1.2*2.25m
Weights
Approx. 3300kg ((based on the S150L01 model as a
reference, actual weight may vary for other models
received)
Air conditioner power
3kW (cooling capacity)
Working environment temperature
-20~50°C
Working environment humidity
0~95%（non-condensing）
Protection level
IP55
Anti-corrosion grade
C3
Noise
≤75dB
Elevation
≤3000m（Above 2000m need to reduce the
amount）
Cooling method
Air cooling
Demonstrate
Touch screen (optional)
Fire-fighting
Optional: Aerosol/heptafluoropropane (FM-
200)/perfluorohexanone (Novec1230)
EMS external communications
Ethernet
Certification
CE、CQC
Core Modules
Battery Modules
DANGER
 Do not touch any batteries while the BESS is running.

Only authorized operators should handle the batteries
 End of life (should be decommissioned, disassembled and disposed of in accordance
with the recycling program provided).
This product uses LFP battery modules (LiFePO4), which have excellent safety, long
service life, good temperature performance, high energy density, low cost, pollution-free
modular assembly, high strength, and high structural reliability with low maintenance
costs. The appearance of the battery module is shown below:
Figure 3-7 The appearance of battery module
