System parameters
The BESS parameters for each type of DH200F, including S150L00, S100L00, S050L00,
S000L00, S150L01, S100L01, S050L01, and S000L01, are summarized in the following table:
Table 3-8 BESS Parameter Sheet
Battery system specification parameters: (Applicable to all models)
Battery type
lithium iron phosphate (LiFePO4)
Battery capacity
280Ah
Single module battery configuration
1P16S
Number of packs
One cluster/15 modules
Battery voltage range
672~864V
Rated current
140A（0.5C）
Maximum current
150A
System storage capacity
215kWh
AC specification parameters (on-grid): (Applicable to all models)
Rated power
100kW
Rated AC voltage
400V
Wiring method
3P4L+PE
Frequency
50Hz
Maximum AC current
158A
Maximum number of BESS units be
paralleled
12
AC specification parameters (off-grid): (Applicable only to models S150L01, S100L01,
S050L01, S000L01)
Rated power
100kW
Rated AC voltage
400V
Wiring method
3P4L+PE
Frequency
50Hz
Maximum AC current
158A
Unbalanced load carrying capacity
100%
On-grid to off-grid switching time
＜20ms
Off-grid to on-grid switching time
＜20ms
Maximum number of BESS units be
paralleled
5
PV access: (Applicable to all models, the "S" followed by a number represents the PV
power. For example, S150L00 indicates a 3-channel MPPT with a power of 150 kW.)
Input voltage
200-670V
Number of MPPT paths
0~3
