EA UltraTEV Plus 2 - Page 39

2388-MANUL-V10.00.00-UTP2 Operating Manual
Page 34 of 74
Form
3
Name
Switchgear
Field
Description
Behaviour
Manufacturer
Manufacturer name of the
switchgear being surveyed
Pressing the input field will show a populated list
of switchgear manufacturers, with the option to
enter a custom value using the virtual keyboard
Type
The type of switchgear being
surveyed
Pressing the input field will show a populated list
of switchgear types with the option to enter a
custom value using the virtual keyboard
Installation
Date
Installation date of the switchgear
Pressing the input field will show a date selector
to input the switchgear installation date
Rated Voltage
The rated voltage of the switchgear
Pressing the input field will show a populated list
of voltages with the option to enter a custom
value using the virtual keyboard
Operating
Voltage
The operating voltage of the
switchgear
Pressing the input field will show a populated list
of voltages with the option to enter a custom
value using the virtual keyboard
Busbar
Insulation
The insulation material of the
switchgear's busbar
Pressing the input field will show a populated list
of busbar insulation materials with the option to
enter a custom value using the virtual keyboard
Form
4
Name
Conditions
Field
Description
Behaviour
Background
Metal
Background metalwork TEV value
Pressing the input field will cause a background
TEV measurement to be performed
Background
Air
Background Air TEV value
Pressing the input field will cause a background
TEV measurement to be performed
Temperature
Temperature as read by the
Environmental Sensor
Pressing the input field will cause it to be
populated with the current Temperature. The
Temperature & Humidity sensor must be
connected to do this.
Humidity
Humidity as read by the
Environmental Sensor
Pressing the input field will cause it to be
populated with the current Humidity. The
Temperature & Humidity sensor must be
connected to do this.
