Eagle 200-DC - Emergency Release; Adjusting the Clutch

23
Emergency Release
Clutch
BY
EA
G
LE
A
C
C
ESS C
O
N
T
R
OL
S
Y
STEM
S,
INC.
Emergency Release
Unscrew bolt, remove top cap
and rotate easy release lever.
These two
gaps should
remain even
for proper fit.
3
Wire
24V
RADIO POWER
RELAY
RELAY RET
3214
(24V)
COMMON GROUND
4
Wire
24V
RADIO POWER
RELAY
(24V)
RET
Adjusting the Clutch
Depending on the weight of the gate, clutch
slippage may occur. Typical clutch slippage is
about 1/4 turn. If it does not slip, re-adjust the
clutch accordingly.
Diamond DC Board ONLY
