Eagle 200-DC - METHODS OF INSTALLATION; Standard Installation; Compact Installation

6
Installation
METHODS OF INSTALLATION
Standard Installation
An experienced installer should perform the installation. Improper installation may result in property damage, severe injury or death.
Read the entire manual before proceeding with the installation.
Eagle Access Control Systems, Inc. is not responsible for researching and complying with local building codes. Be sure to check all local
building codes before installation.
Recommended Concrete
Pad Dimensions:
Eagle-100 - 20” x 24”
Eagle-200 - 24” x 24”
Use four 1/2” x 3 1/2”
minimum, up to 1/2” x 6”
sleeve anchors to mount
operator to concrete pad.
NOTE: If there is limited area for
the arm and this dimension is
less than 35 inches then compact
installation is necessary.
Hinge Center
Hinge Center
Hinge Center
Hinge Center
Concrete Pad
Concrete Pad
Closed Gate
Closed Gate
Open Gate
Wall
Open Gate
A
E
I
F
G
H
24”
B
J
C
D
2”
Eagle-100 - 19.5”
Eagle-200 - 21.75”
28
30
32
35
Option 1
Option 2
Option 3
Option 4
27.5
29.5
25.5
29
34.5
36
39
36
42
43
44
45
BC DE
12
12
12
12
A
35
36
Eagle-100
Eagle-200
22
32
11
12
28
25
FG I
26
27
JH
1/2
Eagle-100 or Eagle-200 - Inches
Compact - Inches
Be sure that arms
are FULLY extended
and locked when
the gate is in the
closed position.
Suggested concrete
depth dimension.
Check local building
codes in your area for
depth of concrete
before installation.
24”
5”
Ground Level
Compact Installation
Securing Operator to Pad
NOTE: If this dimension is less than
16 inches, secondary entrapment
protection is REQUIRED in this area.
See page 8 for more information.
