Eagle 200-DC - Eagle-100-DC; Eagle-200-DC Series Replacement Parts

31
BY
EA
G
LE
A
CCE
S
S
CO
NT
RO
L
S
Y
S
T
E
MS
,
IN
C.
3
Wire
24V
RADIO POWER
RELAY
RELAY RET
3214
(24V)
COMMON GROUND
4
Wire
24V
RADIO POWER RELAY
(24V)
RET
MH4
DIAMOND
DC
M/S PHASE
01
MASTER
OPEN RIGHT
BRAKE ON
REVERSE LOOP NC
ONE PASS ON
STOP-REVERSE ON
ALARM-RESET ON
CLOSE TIMER ON
OFF—ON
SLAVE
OPEN LEFT
BRAKE OFF
REVERSE LOOP NO
ONE PASS OFF
STOP-REVERSE OFF
ALARM-RESET OFF
CLOSE TIMER OFF
1
ON
2 3 45 6 7 8
SELECT
ACTIVE
OVERLOAD
OPENING
LIGHT HEAVY
ERD STATUS
GATE STATUSTIMER
MIN
MAX
CLOSING
OPEN
LIMIT
OPENING CLOSING CLOSE
LIMIT
CLOSE
STOP
OPEN
SLAVE MASTER
#14#13
+ MAGLOCK - (24 VDC)
#10
+ ALARM - (12 VDC)
#11
MAG LOCK
N / C N / O COM
#9
POWER
24 VDC
#12
REVERSE LOOP
#2
SHADOW LOOP
#3
EXIT OPEN
#4
KEY KEYPAD
#6
EDGE SENSOR
#8
STOP
#5
CLOSE
#7
LOOP WIRE INPUT
EXIT
OPEN
SHADOW
LOOP
REVERSE
LOOP
COMM PORT
OUTPUTSGLOBAL INPUTS
RECEIVER
RELAY
-24VDC
RELAY
24VDC
#1
REVERSE LOOP SHADOW LOOP EXIT LOOP
REVERSE SHADOW EXIT
RESET
+ –
+ –
+ –+ –
GND CLK GND CLK
AC POWER
24VAC
SOLAR
POWER
LOW
BATTERY
CHARGER
ON
FUSE MAX 20A
FUSE MAX 35A
20
FUSE MAX 20A
MOTOR
+–
BATTERY
+
24VAC
HNG –
LEFT RIGHT GND GND LEFT RIGHT
20
SOLAR
+–
–
1
2
3
+
OFF
OFF
OFF
1
ON
2 3 4
P/O ADJUST
1
ON
2 3 4
AUTO OPEN OFF
POWER FAIL OPEN
OPEN DELAY MASTER OFF
OPEN DELAY SLAVE OFF
AUTO OPEN ON
POWER FAIL CLOSE
OPEN DELAY MASTER ON
OPEN DELAY SLAVE ON
OFF—ON
PWR FAIL OPERATION
20 Amp
MH2
MH1
MH3
Eagle-100-DC / Eagle-200-DC Series Replacement Parts
E101 - Eagle-100-DC Limit Switch Assembly (Complete)
E102 - Eagle-100-DC Limit Switch Bracket
E103 - Limit Switch
E104 - Eagle-200-DC Limit Switch Bracket
E105 - Eagle-200-DC Limit Switch Assembly (Complete)
E111 - Eagle-100-DC Operator Cover
E114 - Eagle-100-DC Release Cover
E115 - Eagle-100-DC Release Cover Cap
E116 - Easy Release Main Swing Arm
E130 - Electrical Outlet
E131 - Power Switch
E146 - Pulley (SGR)
E147 - 2 1/2” Motor Pulley
E151 - Eagle-200-DC Drive Chain (Top Position)
E152 - Clutch Kit (Complete)
E153 - Eagle-200-DC Sprocket (SGR)
E173 - V-Belt
E175 - Limit Switch Activator
E180 - Eagle-200-DC Primary Gear Reducer (PGR)
E182 - Eagle-100-DC Primary Gear Reducer (PGR)
E186 - Secondary Gear Reducer (SGR)
E190 - Eagle-200-DC Chassis
E191 - Control Board Box
E192A - Eagle-200-DC Right Chassis Leg
E192B - Eagle-200-DC Left Chassis Leg
E193 - Eagle-200-DC Leg Bracket
E195 - Eagle-100-DC Chassis
E196A - Eagle-100-DC Right Chassis Leg
E196B - Eagle-100-DC Left Chassis Leg
E197 - Eagle-100-DC Leg Bracket
E222 - Eagle-200-DC Operator Cover
E223 - Operator Cover Door Frame
E224 - Operator Cover Door
E225 - Eagle-200-DC Release Cover
E226 - Eagle-200-DC Release Cover Cap
E471 - Large Arm
E472 - Small Arm
E473 - Arm Attachment Plate
E475 - Extension Arm
E476 - Weld Plate (Gate Attachment Bracket)
E515 - Swing Arm Assembly (Complete)
E525 - Plastic Eagle Logo Plaque
E600 - Diamond DC Control Board
E721 - Arm Hub
E722 - Plastic Cup
E723 - Sprocket (PGR)
E724 - Pillow Block
E725 - Limit Sprocket
E726 - Limit Shaft
E727 - Limit Box
E728 - Eagle-100-DC Drive Chain (Top Position)
E729 - Drive Chain (Side Position)
EG054 - 12 VDC 7 Amp Battery Pack
EG059 - 12 VDC 9 Amp Battery Pack
EG052 - 12 VDC 35 Amp Battery Pack
E-Number Part Description
Right
Leg
Left
Leg
E180/
E182
Right
E192A/
E196A
Left
E192B/
E196B
E193/
E197
E727
E725
E175
E190/
E195
E724
E151/
E728
E721
E116
E722
E723
E225/
E114
E226/
E115
E222/
E111
Complete Limit
Switch Assembly
E105/E101
Battery Packs
EG054 - 12 VDC 7 Amp
EG059 - 12 VDC 9 Amp
EG052 - 12 VDC 35 Amp
Complete Clutch Kit E152
Complete Swing
Arm Assembly
E515
E223
E224
E525
E186
E146
E147
E103
E473
E471
E472
E475
E476
E102/
E104
E173
E191
E600
E131
E726
E130
E153
E729
If you are uncertain about a specific
part you may need, please call us for
assistance:
1-800-708-8848
Diamond DC Board Replacement Parts
Diamond DC Board ONLY
