Configuration Using the PROFIBUS Configuration File
C441 PROFIBUS Module User Manual MN042002EN—July 2015 www.eaton.com 23
Motor Phase Loss Trip Level S811+ 1–100%
Motor Phase Loss Duration S811+ 0.1–60.0 sec (in 0.1 sec)
Motor Phase Imbalance Fault Enable S811+ 0 = Protection disabled
1 = Fault enabled
2 = Warning enabled
Motor Phase Imbalance Fault Level S811+ 1–100%
Motor Phase Imbalance Fault Duration S811+ 0.1–60.0 sec (in 0.1 sec)
Motor Voltage Imbalance Fault Level S811+ 1–100%
Motor Voltage Imbalance Fault Duration S811+ 0.1–60.0 sec (in 0.1 sec)
Motor Under Voltage Fault Enable S811+ 0 = Protection disabled
1 = Fault enabled
2 = Warning enabled
Motor Under Voltage Fault (% of Rated Voltage) S811+ 1–99%
Motor Under Voltage Fault Duration (Running) S811+ 0.1–60.0 sec (in 0.1 sec)
Motor Over Voltage Fault Enable S811+ 0 = Protection disabled
1 = Fault enabled
2 = Warning enabled
Motor Over Voltage Fault (% of Rated Voltage) S811+ 101–120%
Motor Over Voltage Fault Duration S811+ 0.1–60.0 sec (in 0.1 sec)
Motor Line Frequency Fault (Warning) Enable, Len=1 S811+ 0 = Protection disabled
1 = Fault enabled
2 = Warning enabled
Motor Line Frequency Deviation From Rated Fault
Level
S811+ 0–100% deviation from setting
Motor Line Frequency Fault Duration S811+ 0.1–60.0 sec (in 0.1 sec)
Motor Average Power Fault (Warning) Enable S811+ 0 = Protection disabled
1 = Fault enabled
2 = Warning enabled
Motor Average Power Percent Rated Low Fault Level S811+ 0.0–100.0% (in 0.1%)
Motor Average Power Percent Rated High Fault Level S811+ 0.0–800.0% (in 0.1%)
Motor Average Power Fault Duration S811+ 0.1–60.0 sec (in 0.1 sec)
Analog Input Fault (Warning) Enable S811+ 0 = Protection disabled
1 = Fault enabled
2 = Warning enabled
Analog Input Percent of Rated Range Low Fault Level S811+ 0–100% (of range)
Analog Input Percent of Rated Range High Fault Level S811+ 0–100% (of range)
Analog Input Fault Duration S811+ 0.1–60.0 sec (in 0.1 sec)
Temperature Sensor Fault Enable S811+ 0 = Protection disabled
1 = Fault enabled
2 = Warning enabled
SCR Not Firing Fault Enable S811+ 0 = Protection disabled
1 = Fault enabled
2 = Warning enabled
SCR Shorted Fault Enable S811+ 0 = Protection disabled
1 = Fault enabled
2 = Warning enabled
Alarm No Trip Enable S811+ 1 = enable
0 = disable
Table 20. S811+ Soft Starter Configuration File, continued
Parameter Name Location Notes
