Eaton M-Max series Quick Start Guide

M-Max Series adjustable frequency drive
MN04020002E
For more information visit: www.eaton.com
1
February 2010
M-Max  Series
About this manual
Notes about the M-Max Series product enhancement
This third edition of the quick reference guide describes the extended functionality (as of
production date January 2010, see Figure 1 ) of the M-Max Series of adjustable frequency drives .
Key features of this enhancement are:
● New controller board with a higher-performance microprocessor
● Field bus interfaces on device side 
●
Two additional control keys 
● Extended functionality of the digital and analog inputs and outputs 
Figure 1: M-Max Series Adjustable Frequency Drive
I
OK
B
A
C
K
RESE
T
L
O
C
REM



