Eaton M-Max series Quick Start Guide

M-Max Series adjustable frequency drive
32 For more information visit: www.eaton.com
MN04020002E
February 2010
Table 10: Predefined Application Parameters From Parameter P1.2

230V = MMX11..., MMX12…, MMX32…480V = MMX34…

Depends on performance variables.
Parameters Designation
Basic
(Standard Drive) Pump Drive Fan Drive
Feed Unit
(High Load)
P1.1 Parameter
range
1 = Only quick
configuration
parameters
1 = Only quick
configuration
parameters
1 = Only quick
configuration
parameters
1 = Only quick
configuration
parameters
P1.2 Application 0 = Basic 1 = Pump drive 2 = Fan drive 3 = Hoisting
device
(high load)
P6.1 Control level 1 = Control
signal terminals
(I/O)
(I/O)
1 = Control
signal terminals
(I/O)
(I/O)
1 = Control
signal terminals
(I/O)
(I/O)
1 = Control
signal terminals
(I/O)
(I/O)
P6.2 Set point input
(0 – 10 V) for
terminal 2
3 = AI1 (analog
set point 1)
3 = AI1 (analog
set point 1)
3 = AI1 (analog
set point 1)
3 = AI1 (analog
set point 1)
P6.3 Minimum
frequency
0.00 Hz 20.00 Hz 20.00 Hz 0.00 Hz
P6.4 Maximum
frequency
60 Hz 60 Hz 60 Hz 60 Hz
P6.5 Acceleration
time (acc1)
3.0s 5.0s 20.0s 1.0s
P6.6 Deceleration
time (dec1)
3.0s 5.0s 20.0s 1.0s
P6.8 Stop function 0 = Free coasting 1 = Deceleration
time (ramp)
0 = Free coasting 0 = Free coasting
P7.1 Motor, Rated
current

I
e
I
e
I
e
I
e
P7.3 Motor, rated
speed
(rpm)

1440/1720 rpm 1440/1720 rpm 1440/1720 rpm 1440/1720 rpm
P7.4 Motor, power
factor (cos )

0.85 0.85 0.85 0.85
P7.5 Motor, rated
operating
voltage
230/480V

230/480V

230/480V

230/480V

P7.6 Motor, rated
frequency
60 Hz 60 Hz 60 Hz 60 Hz
P11.7 Torque
increase
0 = Deactivated 0 = Deactivated 0 = Deactivated 1 = Enabled
M1.1 Output
frequency
0.00 Hz 0.00 Hz 0.00 Hz 0.00 Hz
