Eaton M-Max series Quick Start Guide

M-Max Series adjustable frequency drive
MN04020002E
For more information visit: www.eaton.com 31
February 2010
Table 9: Quick Configuration (continued)
Table 10 shows the preset application parameters of parameter P1.2.
PNU ID
Access
Right
RUN Designation Value Range
Factory
Setting
User
Setting
P6.6 104 — Deceleration
time (dec1)
0.1 – 3000s 3.0
P6.7 505 — Start function 0 = Acceleration time (ramp)
1 = Flying restart circuit
0
P6.8 506 — Stop function 0 = Free coasting
1 = Deceleration time (ramp)
0
P7.1 113 — Motor, rated
current
0.2 x I
e
... 2 x I
e
( Motor rating plate)
I
e
P7.3 112 — Motor, rated
speed
300 – 20,000 rpm
( Motor rating plate)
1720
P7.4 120 — Motor, power
factor (cos )
0.30 – 1.00
( Motor rating plate)
0.85
P7.5 110 — Motor, rated
operating
voltage
180 – 500V
( Motor rating plate)
230/480
P7.6 111 — Motor, rated
frequency
30 – 320 Hz
( Motor rating plate)
50.00
P11.7 109 — Torque increase 0 = Deactivated
1 = Enabled
0
M1.1 1 — Output
frequency
Hz 0.00
