Eaton M-Max series Quick Start Guide

M-Max Series adjustable frequency drive
2
For more information visit: www.eaton.com
MN04020002E
February 2010
Figure 2: Control Signal Terminals
This quick reference guide contains selected information about the M-Max Series adjustable
frequency drives.
This quick reference guide is a summary of manual MN04020001E and contains technical
data, parameter lists and information about operating the adjustable frequency drives. It is
intended to support experienced, qualified users in the use of the M-Max Series adjustable
frequency drive.
It is assumed that you have thoroughly read manual MN04020001E and that the adjustable
frequency drive has been correctly installed and commissioned as described in manual
MN04020001E and installation instructions IL04020001E.
12367
8
9
10 25
24
4 5 13 14 15 16 18 20 22 23 26
AI2
GND DO– DI4 DI5 DI6 AO DO+
R13
R14 – R24
+ 10V AI1 GND 24V Dl-C DI1 DI2 DI3 A
LOGIC
AJ 1
– +
V mA
AJ 2
V mA
RS 485
Term
B R21 R22
