Eaton M-Max series Quick Start Guide

M-Max Series adjustable frequency drive
MN04020002E
For more information visit: www.eaton.com 7
February 2010
Technical Data
Table 3: Technical Data

Rated motor currents for normal four-pole internally cooled and surface-cooled three-phase asynchronous motors
(1500 rpm at 50 Hz, 1800 rpm at 60 Hz).

Calculated motor rating (no normalized value). The mains voltage of 115V is raised to 230V (output voltage) through
an internal voltage double connection.
Part Number
Rated
Opera-
tional
Current
Overload
Current
(150%) Assigned Motor Rating
Installation
Size
I
e
I
e150
P (230V, 50 Hz) P (230V, 60 Hz)
[A] [A] [kW] [A]

[hp] [A]

Power Connection Voltage: 1 AC 115V, 50/60 Hz (94 – 132V ± 0%, 45 – 66 Hz ± 0%)
MMX11AA1D7.... 1.7 2.6 0.25 1.4 1/3

1.5

FS2
MMX11AA2D4.... 2.4 3.6 0.37 2.0 1/2 2.2 FS2
MMX11AA2D8.... 2.8 4.2 0.55 2.7 3/4 2.2 FS2
MMX11AA3D7.... 3.7 5.6 0.75 3.2 1 3.2 FS2
MMX11AA4D8.... 4.8 7.2 1.10 4.6 1-1/2 4.2 FS3
Power Connection Voltage: 1 AC 230V, 50/60 Hz (177 – 264V ± 0%, 45 – 66 Hz ± 0%)
MMX12AA1D7.... 1.7 2.6 0.25 1.4 1/3

1.5

FS1
MMX12AA2D4.... 2.4 3.6 0.37 2.0 1/2 2.2 FS1
MMX12AA2D8.... 2.8 4.2 0.55 2.7 3/4 2.2 FS1
MMX12AA3D7.... 3.7 5.6 0.75 3.2 1 3.2 FS2
MMX12AA4D8.... 4.8 7.2 1.10 4.6 1-1/2 4.2 FS2
MMX12AA7D0.... 7.0 10.5 1.50 6.3 2 6.8 FS2
MMX12AA9D6.... 9.6 14.4 2.20 8.7 3 9.6 FS3
Power Connection Voltage: 3AC 230V, 50/60 Hz (177 – 264V ± 0%, 45 – 66 Hz ± 0%)
MMX32AA1D7.... 1.7 2.6 0.25 1.4 1/3

1.5

FS1
MMX32AA2D4.... 2.4 3.6 0.37 2.0 1/2 2.2 FS1
MMX32AA2D8.... 2.8 4.2 0.55 2.7 3/4 2.2 FS1
MMX32AA3D7.... 3.7 5.6 0.75 3.2 1 3.2 FS2
MMX32AA4D8.... 4.8 7.2 1.10 4.6 1-1/2 4.2 FS2
MMX32AA7D0.... 7.0 10.5 1.50 6.3 2 6.8 FS2
MMX32AA011.... 11.0 14.4 2.20 8.7 3 9.6 FS3
