Table 2:
General Rated Operational Data
Technical data Unit Value
General
Standards and regulations EMC: IEC/EN 61800-3,
Safety: IEC/EN 61800-5, UL 508C
Certifications and manufacturer’s
declarations on conformity
EMC: CE, CB, c-Tick
Safety: CE, CB, UL, cUL, phenum rated
Production quality RoHS, ISO  9001
Climatic proofing < 95%, average relative humidity,
noncondensing (EN 50178)
Air quality
Chemical vapors IEC 721-3-3: Device in operation, Class 3C2
Mechanical particles IEC 721-3-3: Device in operation, Class 3S2
Ambient temperature
Operation ºC –10 to +50

Storage ºC –40 to +70
Installation altitude H 0 – 1000m above sea level, over 1000m with 1%
power reduction per 100m, maximum 2000m,
at maximum +50ºC ambient temperature.
2000m maximum for corner grounded device,
4500m for non-corner grounded device
Mounting position Vertical (± 90 degrees lateral rotation)
Protection type IP20
Busbar tag shroud BGV A3 (VBG4, finger and back-of-hand safe)
Overvoltage category/degree of
pollution
—
Mechanical shock resistance IEC 68-2-27
Storage and transport: 15g, 11 ms
(in the packaging)
UPS drop test (for applicable UPS weights)
Vibration EN 60068-2-6
3 – 150 Hz, oscillation amplitude 1 mm (Peak)
at 3 – 15.8 Hz, maximum acceleration amplitude 1g
at 15.8 – 150 Hz
Emitted interference with internal EMC
filter (maximum motor cable length)
C2: Class A in 1st environment (residential area with
commercial utilization)
C3: Class A in 2nd environment (Industrial)
MMX11 C2 (5m), C3 (30m)
MMX12, MMX32 C2 (5m), C3 (30m)
MMX34 C2 (5m), C3 (30m)
Power Section
Rated operational voltage at 50/60 Hz ±10 %
MMX11 U
e
1 AC 115V (110V – 15% ... 120V + 10%)
MMX12 U
e
1 AC 230V (208V – 15% ... 240V + 10%)
MMX32 U
e
3 AC 230V (208V – 15% ... 240V + 10%)
MMX34 U
e
3 AC 400V (380V – 15% ... 480V + 10%)
