M-Max Series adjustable frequency drive
30 For more information visit: www.eaton.com
MN04020002E
February 2010
List of parameters
Quick configuration (basis)
The quick-start assistant can be switched off in the first parameter (P1.1) by entering a zero
(access to all parameters).
In parameter P1.2, you can switch to the specified application setting with the quick-start
assistant (see Table 10 on Page 32).
The quick-start assistant ends this first cycle by automatically switching to frequency display
(M1.1 = 0.00 Hz).
By selecting the parameter level (PAR) again, besides the selected parameters for the
quick-configuration, the system parameters (S) are also shown in other cycles.
Table 9: Quick Configuration
Detailed information on the individual parameters is provided in the
manual MN04020001E
When first switching on or after activating the default settings (S4.2 = 1), you are
guided step by step through the provided parameters by the quick-start assistant.
The defined values are confirmed with the OK button or they can be changed to suit
your application and the motor data.
PNU ID
Access
Right
RUN Designation Value Range
Factory
Setting
User
Setting
P1.1 115 ✓ Parameter range 0 = All parameters
1 = Only quick configuration
parameters
1
P1.2 540 — Application 0 = Basic
1 = Pump drive
2 = Fan drive
3 = High starting load
0
P1.3 1472 — Factory setting
(WE),
Country-specific
(enabled and visible only in the Quick
Start wizard)
0 = EU (50 Hz defaults)
1 = USA (60 Hz defaults)
0
P6.1 125 ✓ Remote control
place
1 = Control signal terminals (I/O)
2 = Control unit (KEYPAD)
3 = Field bus (BUS)
3
P6.2 117 ✓ Remote
reference
0 = Fixed frequency (FF0)
1 = Keypad (REF)
2 = Field bus (BUS)
3 = AI1 (analog set point 1)
4 = AI2 (analog set point 2)
5 = Motor potentiometer
3
P6.3 101 — Minimum
frequency
0.00 – P6.4 Hz 0.00
P6.4 102 — Maximum
frequency
6.3 – 320.00 Hz 60.00
P6.5 103 — Acceleration
time (acc1)
0.1 – 3000s 3.0
To Next Page
