INSTALLATION
EATON BladeUPS
®
(12 kVA) User's Guide S 164201649 Rev 4www.eaton.com/powerquality
19
S Flexible or rigid metal conduit
S Circuit with overcurrent protection, depending on parallel configuration:
Table 1. BladeUPS Modules Overcurrent Protection
Number of UPSs in Parallel System BladeUPS 12 Module BladeUPS 12i Module
2 100A 63A
3 150A 75A
4 200A 100A
5 225A 125A
6 (N+1 System) 225A 160A
NOTE For ease of wiring access with bottom entry, place the rack containing the UPSs on a raised floor.
Preparing the Rack
To prepare the rack for wiring:
1. Verify that all packaging material is removed from the rack.
2. Verify that the following items are included with the rack:
S (4) leveling feet
S (4) plastic roof caps
S (2) door keys
S (1) package M6 screws with plastic washers
S (1) package matching nuts
3. Verify operation of the rack door handle:
To open the door, push in on the key lock. The handle pops up. Pull out on the
handle.
To close the door, push in on the handle until it snaps into place.
4. Verify that the supplied keys lock and unlock the door.
5. Optional. You may flip the rack door to allow it to open from the opposite side. To
flip the door:
Remove the hinge pins, then remove the door. Move the hinges to the opposite
side of the rack. Reorient the door and hang it on the hinges; replace the hinge
pins.
Reverse the door handle mounting.
NOTE The handle uses gravity to operate properly. Reversing the handle is required.
Move the Eaton logo to the upper part of the door.
