OPERATION
EATON BladeUPS
®
(12 kVA) User's Guide S 164201649 Rev 4www.eaton.com/powerquality
64
The following table shows the indicator status and description.
Indicator Status Description
Green
On The UPS is operating normally.
Flashing S The UPS is starting up or is shut down and waiting for power to
return.
S A new information message is active.
S Bypass is not available.
Off The UPS is turned off and will not turn on automatically.
Yellow
On The UPS is in Battery mode.
Yellow
On The UPS is in Bypass mode.
Red
On The UPS has an active alarm.
Flashing There is a new UPS alarm condition. See “Troubleshooting” on
page 105 for additional information.
Changing the Language
Press and hold the first button on the left for approximately five seconds to select the
language menu. This action is possible from any LCD menu screen.
Display Functions
As the default or after 15 minutes of inactivity, the LCD displays the selectable Start
screen. The default is the Eaton logo and can be changed to the Mimic screen in the
User Settings menu.
The backlit LCD automatically dims after a long period of inactivity. Press any button
to restore the screen.
Press any button to activate the menu options. Use the two middle buttons (
and )
to scroll through the menu structure. Press the
button to enter a submenu. Press
the button to select an option. Press the
ESC
button to cancel or return to the
previous menu.
