The following table shows the basic menu structure.
NOTE Menu functions related to parallel systems appear only on paralleled UPSs.
Table 3. Menu Map for Display Functions
Main Menu Submenu Display Information or Menu Function
UPS Status System Normal | High Efficiency Power: % /
Battery Resting | Battery Floating UPS in Parallel Mode /
Parallel Unit Number x / Units on CAN Bus / Units on Load
Event Log Displays up to 100 events and alarms
Measurements
For more information about
measurements, see
“Metering” on page 88.
Parallel System kW [by unit] / kW [Parallel total]
Output Voltage L-N and L-L / Current / Frequency / Power kW / Power kVA / Power pf
Battery Voltage / Current / Runtime
Input Voltage L-N and L-L / Current / Frequency
Load Receptacle Outlet Voltage / Outlet Current / Outlet Power kW / Outlet Power kVA / Outlet
Frequency
Control
Go to Bypass Mode Transfers the UPS system to internal Bypass mode
When this command is active, the option changes to Go to Normal Mode.
Start Battery Test Initiates a battery test
Display Test Four different selectable tests for the front panel functions: the LEDs cycle through,
the alarm beep sounds, the backlight turns off and on, and the pixels scroll through to
test the LCD.
Settings
User Settings See Table 4 for detail.
Service Settings Not available.
Identification Type / Part Number / Serial Number / Firmware / Display / System Display / CAN
Bridge
Turn UPS On/Off On and Off Options Turn UPS Off / Turn System On / Turn System Off
