Eaton S801+ Series User Manual

Technical Data and Specifications
S801+ Soft Starter MN03900002E—November 2012 www.eaton.com 3
Technical Data and Specifications
Environmental
Environmental Specifications
Physical
Unit Weight and Dimensions
Description Specification
Temperature range
Operating –40° to 122°F (–40° to 50°C)
Storage –58° to 158°F (–50° to 70°C)
Elevation Up to 6600 ft (2000m) above 6600 ft (2000m), derate 0.5% per 330 ft (100m)
Humidity Functional to 95% noncondensing
Operating orientation Any
Pollution degree IEC 60947-1 3
Shock resistance 15g in any direction
Vibration resistance
Operating 3g in any direction
Non-Operating 3g in any direction
Product Size—Inches (mm)
Catalog Number Unit Weight Lbs (kg) Length Width Height
S801+N37… 5.8 (2.6) 7.37 (187.2) 2.66 (67.6) 6.45 (163.9)
S801+N66… 5.8 (2.6) 7.37 (187.2) 2.66 (67.6) 6.45 (163.9)
S801+R10… 10.5 (4.8) 7.92 (201.2) 4.38 (111.3) 6.64 (168.6)
S801+R13… 10.5 (4.8) 7.92 (201.2) 4.38 (111.3) 6.64 (168.6)
S801+T18… 41 (18.6) 12.71 (322.9) 7.65 (194.4) 6.47 (164.4)
S801+T24… 41 (18.6) 12.71 (322.9) 7.65 (194.4) 6.47 (164.4)
S801+T30… 41 (18.6) 12.71 (322.9) 7.65 (194.4) 6.47 (164.4)
S801+U36… 41 (18.6) 12.72 (323.1) 7.73 (196.3) 7.16 (196.3)
S801+U42… 41 (18.6) 12.72 (323.1) 7.73 (196.3) 7.16 (196.3)
S801+U50… 41 (18.6) 12.72 (323.1) 7.73 (196.3) 7.16 (196.3)
S801+V36… 91 (41.4) 16.57 (420.8) 11.05 (280.6) 7.39 (187.8)
S801+V42… 91 (41.4) 16.57 (420.8) 11.05 (280.6) 7.39 (187.8)
S801+V50… 91 (41.4) 16.57 (420.8) 11.05 (280.6) 7.39 (187.8)
S801+V65… 91 (41.4) 16.57 (420.8) 11.05 (280.6) 7.39 (187.8)
S801+V72… 91 (41.4) 16.57 (420.8) 11.05 (280.6) 7.39 (187.8)
S801+V85… 91 (41.4) 16.57 (420.8) 11.05 (280.6) 7.39 (187.8)
S801+V10… 91 (41.4) 16.57 (420.8) 11.05 (280.6) 7.39 (187.8)
