Eaton S801+ Series User Manual

Technical Data and Specifications
4 S801+ Soft Starter MN03900002E—November 2012 www.eaton.com
Short-Circuit Ratings—Component
Short-Circuit Ratings—Enclosed Control (Fuses)
Short-Circuit Ratings—Enclosed Control (Breaker)
Note: For more details on short-circuit protector selections and enclosure sizing, please refer
to the linked spreadsheet on UL’s website at: http://www.ul.com/global/documents/
offerings/industries/buildingmaterials/industrialcontrolpanels/shortcut.Eaton.xls
Note: Suitable for use on a circuit capable of delivering not more than 100,000 rms
symmetrical amperes, 600 volts maximum when protected by Class RK5 fuses.
Note: Suitable for use on a circuit capable of delivering not more than 65,000 rms
symmetrical amperes, 480 volts maximum when protected by a circuit breaker.
Frame Size Fuses Circuit Breaker Voltage SCCR Rating (A)
S801+N… J HFD 600 10 kA
S801+R… RK5/J HFD,HKD 600 10 kA
S801+T… RK5/J HLD 600 18 kA
S801+U… RK5/J HLD 600 30 kA
S801+V… L HND, RD 600 42 kA
Frame Size Fuses Voltage
SCCR
Rating (A)
Switch
Size (max), A Switch Type
S801+N… J 600 100 kA 100 K
S801+R… RK5/J 600 100 kA 200 K
S801+T… RK5/J 600 100 kA 600 K
S801+U… RK5/J 600 100 kA 600 K
S801+V36… RK5/J 600 100 kA 600 K
S801+V42… L 600 100 kA 800 K
S801+V50… L 600 100 kA 800 K
S801+V72… L 600 100 kA 1200 ND
S801+V85… L 600 100 kA 1200 ND
S801+V10… L 600 100 kA 2000 K
Frame Size
Thermal Magnetic
Circuit Breaker
Motor Circuit
Protector Voltage
SCCR
Rating (A)
Max Size
(breaker) A
S801+N… HFD HMCP 600 10kA 150
S801+R… HFD,HKD HMCP 600 10kA 150, 300
S801+T… HLD HMCP 600 18kA 600
S801+U… HLD HMCP 600 18kA 600
S801+V… HND, RD HMCP 600 35kA, 42kA 1000, 2000

Eaton S801+ Series Specifications

General

Product Series	S801+
Category	Controller
Input Voltage	24 VDC
Output Voltage	24 VDC
Number of Inputs	8
Protection Class	IP20
Communication Protocol	Modbus
