Installation
S801+ Soft Starter MN03900002E—November 2012 www.eaton.com 9
Approximate Dimensions in inches (mm)
S801+V…
4X Ø
0.2650
(6.731)
6.50
(165.1)
7.39
(187.8)
11.05 (280.6)
16.57
(420.8)
2X
15.63
(397.0)
6.79 (172.5)
3.05
(77.5)
9.84 (250.0)
0.236
(6.00)
