Eaton S801+ Series User Manual

Appendix A—Parameters
36 S801+ Soft Starter MN03900002E—November 2012 www.eaton.com
Appendix A—Parameters
Soft Start Config—S801+ …N3S Standard
Soft Start Config
Line Connected Motor Units Minimum Maximum Default Notes
Overld Trip FLA
S801+N37… Amps 11 37 11 Motor FLA parameter must be set to motor
nameplate FLA to achieve proper overload
protection
S801+N66… Amps 20 66 20
S801+R10… Amps 32 105 32
S801+R13… Amps 42 135 42
S801+T18… Amps 56 180 56
S801+T24… Amps 75 240 75
S801+T30… Amps 95 304 95
S801+U36… Amps 112 360 112
S801+U42… Amps 131 420 131
S801+U50… Amps 156 500 156
S801+V36… Amps 112 360 112
S801+V42… Amps 131 420 131
S801+V50… Amps 156 500 156
S801+V65… Amps 203 650 203
S801+V72… Amps 225 720 225
S801+V85… Amps 265 850 265
S801+V10… Amps 312 1000 312
Overload On Disable On
Jam On Disable On
Stall On Disable On
Phase Loss On Disable On
Phase Reversal On Disable On
Reset Mode Manual Auto Manual
Ramp Start/Current Limit Ramp Current Ramp
Kick Start Torque % 0 85 0
Kick Start Time Seconds 0 2 0
Initial Torque % 0 85 45
Ramp Time Seconds 0.5 180 20
Ovrld Trip Class 5 30 20
Soft Stop Time Seconds 0 60 0
