Eaton S801+ Series User Manual

Installation
8 S801+ Soft Starter MN03900002E—November 2012 www.eaton.com
Approximate Dimensions in inches (mm)
S801+T…
S801+U…
11.77
(299.0)
12.71
(322.9)
6.47 (164.4)
7.65 (194.4)
5.40
(137.3)
5.95
(151.1)
5.91 (150.0)
0.28
(7.1)
6X Ø
2.95
(75.0)
11.77
(299.0)
7.16 (181.8)
6X Ø
12.72
(323.1)
6.09
(154.8)
6.64
(168.6)
2.60
(66.0)
0.28
(7.1)
5.20 (132.0)
7.73 (196.3)

Eaton S801+ Series Specifications

General

Product Series	S801+
Category	Controller
Input Voltage	24 VDC
Output Voltage	24 VDC
Number of Inputs	8
Protection Class	IP20
Communication Protocol	Modbus
