Eaton S801+ Series User Manual

Installation
S801+ Soft Starter MN03900002E—November 2012 www.eaton.com 11
Line and Load Power Wiring, S801+T…, S801+U…, and S801+V…
Notes
2
CSA approved 350–500 MCM.
3
Requires special lug cover.
Note: S801+T…, S801+U…, and S801+V… units are
supplied standard without lugs. One kit consists of
required hardware to make connections for three (3)
phases on either line or load side of the soft starter.
Catalog
Number
Conductor
Size
Number of
Conductors
Torque
Lb-in (Nm) Lug Kit
Kits
Required
S801+T… 4–1/0 MCM 2 250 (28.3) EML22 2
4/0–500 MCM 1 250 (28.3) EML23
4/0–500 MCM 2
2
250 (28.3) EML24
2/0–300 MCM 1 225 (25.5) EML25
2/0–300 MCM 2 225 (25.5) EML26
S801+U… 4–1/0 MCM 2 250 (28.3) EML22 2
4/0–500 MCM 1 250 (28.3) EML23
4/0–500 MCM 2
2
250 (28.3) EML24
2/0–300 MCM 1 225 (25.5) EML25
2/0–300 MCM 2 225 (25.5) EML26
S801+V… 4/0–500 MCM 2
2
250 (28.3) EML28 2
4/0–500 MCM 4
2
250 (28.3) EML30
4/0–500 MCM 6
23
250 (28.3) EML32
2/0–300 MCM 4 225 (25.5) EML33
