3-O&M_Settings_r1r Section 3Page 20
EBTRON, Inc • 1663 Hwy 701 S., Loris, SC 29569 • Toll Free: 800-2EBTRON (232-8766) • Fax: 843-756-1828 • EBTRON.com
3.5.6. AO1 Full Scale Reading [AO1 FS]
The airflow rate that results in an output signal of 100%.
[Menu path: SETTINGS >↓ ANALOG OUT >↓ AO1 FS]
Default and Optional Settings: See appropriate probe type
The output signal is linear to airflow (or pressure on -B probe types configured for
DPCONVERT=YES).
3.5.6.1. -P PROBE TYPES
3.5.6.1.1. AO1 UM = FPM [m/s]
Default: 5000 (FPM) [25.0 (m/s)]
Optional Settings: 100 to 15000 (FPM) [0.5 to 75.0 (m/s)]
3.5.6.1.2. AO1 UM = CFM [L/s]
Default: {5000 x AREA} (CFM) [{25000 x AREA} (L/s)]
Optional Settings: 5 to 999999 (CFM) [5 to 999999 (L/s)]
3.5.6.2. -U AND -T PROBE TYPES
3.5.6.2.1. AO1 UM = FPM [m/s]
Default: 3000 (FPM) [15.0 (m/s)]
Optional Settings: 100 to 15000 (FPM) [0.5 to 75.0 (m/s)]
3.5.6.2.2. AO1 UM = CFM [L/s]
Default: {3000 x AREA} (CFM) [{15000 x AREA} (L/s)]
Optional Settings: 5 to 999999 (CFM) [5 to 999999 (L/s)]
3.5.6.3. -F PROBE TYPE
3.5.6.3.1. AO1 UM = FPM [m/s]
Default: 10000 (FPM) [50.0 (m/s)]
Optional Settings: 100 to 15000 (FPM) [0.5 to 75.0 (m/s)]
3.5.6.3.2. AO1 UM = CFM [L/s]
Default: {10000 x AREA} (CFM) [{50000 x AREA} (L/s)]
Optional Settings: 5 to 999999 (CFM) [5 to 999999 (L/s)]
3.5.6.4. -B PROBE TYPE
3.5.6.4.1. AO1 UM = FPM [m/s]
Default: 3000 (FPM) [15.0 (m/s)]
Optional Settings: 100 to 15000 (FPM) [0.5 to 75.0 (m/s)]
3.5.6.4.2. AO1 UM = CFM [L/s]
Default: {3000 x AREA} (CFM) [{15000 x AREA} (L/s)]
Optional Settings: 5 to 999999 (CFM) [5 to 999999 (L/s)]
