Ebtron Advantage IV Series User Manual

Advantage IV and EB-Flow2 Product Lines
O&M MANUAL
Section 4 – Built-in Tools
4-O&M_Tools_r1g Section 4Page 1
EBTRON, Inc • 1663 Hwy 701 S., Loris, SC 29569 • Toll Free: 800-2EBTRON (232-8766) • Fax: 843-756-1828 • EBTRON.com
4. SECTION OVERVIEW
This section discusses the built-in tools provided with each transmitter to facilitate setup, startup and
verification.
4.1. TOOLS MENU ACCESS AND NAVIGATION
The TOOLS menu contains the following submenu categories:
• AREA WIZ (Area Wizard)
• FAN WIZ (Fan Area Wizard)
• FAW (Flow Adjust Wizard)
• TEST OUT (Test Analog Output)
• TEST RELAY (Test Relay)
• LOCK (Lock Parameters and Wizards)
Simultaneously press the ↑↓ pushbuttons during normal operation to enter the main menu. The transmitter
will continue to operate normally in the background.
The SETTINGS menu will be displayed. Press ↓ once and the TOOLS menu will be displayed. Press the
ENT pushbutton to select the top of the TOOLS submenu category.
The TOOLS menu block diagram is shown below.
FIGURE 4-1 TOOLS MENU BLOCK DIAGRAM
SETTINGS
Tool 1
ENT
ESC
Tool n
ESC
TOOLS
DIAGNOSTICS
↑ or ↓
↑ or ↓
NORMAL
OPERATION
↑ + ↓
ESC
ESC
ESC
Execute Tool 1
ENT
ESC
Execute Tool n
ENT
ESC
↑ or ↓
