2.2.2.1. SYSTEM OF UNITS
The transmitter is factory set to I-P system of units. Set the system of units (SYS) to SI if required. See
Section 3 for more information.
Verify the following:
 The transmitter is displaying airflow and temperature in the proper system of units.
 Changing the system of units restores factory default settings. Modifications made by the user are
lost.
2.2.2.2. DUAL LOCATION OPERATION
2.2.2.2.1. Advantage IV Product Line
Advantage IV models having the number 2 in the fourth digit of the transmitter model code are configured for
two measurement locations.
2.2.2.2.2 EB-Flow2 Product Line
EB-Flow2 remote transmitters support two measurement locations. EB-Flow2 transmitters serving two
measurement locations must be configured for 2 locations for dual location operation. Set the LOCATIONS
parameter to 2. The locations parameter is located in the GLOBAL submenu of the SETTINGS menu. See
Section 3 for more information.
Verify the following:
 The LOCATIONS parameter is set to 2.
 Changing the transmitter from 1 to 2 locations, or vice versa, restores factory default settings for the
system of units selected. Modifications made by the user are lost.
2.2.2.2.3. All Product Lines
Inspect and verify the following:
 The probes are connected to the transmitter properly for two locations. See Section 1 for more
information.
 Dual location applications require that the probes are installed in the proper locations and properly
connected to the transmitter.
2.2.2.3. SETUP WIZARDS
-F, -U and -B probe types are shipped with the area parameter(s) set to {null} (unknown). If volumetric
airflow, CFM [L/s], is required, the area parameters must be determined. The -F/An fan array probe type has
a fan array wizard (FAN WIZ) to configure the number of fans and facilitate area parameter entry. All other
probe types have an area setup wizard (AREA WIZ) to facilitate area parameter determination.
Wizards are accessed from the TOOLS menu. See Section 4 for more information.
2.2.2.4. FREE AREA VERIFICATION
 Verify the area parameter, AREA, matches the actual area where the probes are installed.
 The free area for -P, -U, -T and -B probes is the duct or opening area where the probes are mounted,
less any internal insulation (i.e. the probe blockage does not affect the area calculation).
