Ebtron Advantage IV Series User Manual

5-O&M_Diagnostics_r1e Section 3Page 11
EBTRON, Inc • 1663 Hwy 701 S., Loris, SC 29569 • Toll Free: 800-2EBTRON (232-8766) • Fax: 843-756-1828 • EBTRON.com
TABLE 5-2 TROUBLE CODES (Continued)
Table 5-3 provides a description of each trouble code message. If a trouble code and message is displayed
on the LCD, refer to Section 6 – Troubleshooting or contact EBTRON customer service at 1-800-232-8766.
TABLE 5-3 ERROR MESSAGE DESCRIPTION
Code Error Message
GTx116e-P/H
GTx116e-P
GTx116-P
GTx208e-P
HTx104-P
HTx202-P
EF-x2000-T
EF-x2000-U
GTx108-F/An
GTx108-F
GTx108e-F/An
GTx108e-F
GTx204e-F
HTx104-F
HTx202-F
GTx116-B
HTx104-B
EF-x2000-B
50 Pb SENS ERROR
• • • • • •
60 NUM PROBES
• • • • •
61 FAN COUNT
• •
70 SYSTEM ERROR
• • • • • • • • • • • • • • • • • •
71 OUT CARD
• • • • • • • • • •
72 CON CARD
• • • • •
73 BLE COM ERROR
• • • • • •
74 AOUT ERR
• • • • • •
75 CON BUS
• • • • • •
Error Message Error Description
NO PROBES No probes discovered by transmitter.
WRONG SENS Mismatched sensor probe types on a single transmiter.
Px MISSING Registered probe missing.
Px MEM ERROR Serial memory error in probe.
SENSOR x Sensor node error.
LOW TEMP Airstream temperature below product's specified minimum (-20°F [-28.9°C])
HIGH TEMP Airstream temperature above product's specified maximum (160°F [71.1°C])
RHx MISSING Humidity sensor error.
Pb SENS ERR Barometric pressure sensor error.
NUM PROBES Missing probe at Location 2 (dual location EF units).
FAN COUNT Fan count entry from FAN WIZ does not equal actual sensor probe count.
SYSTEM ERROR Transmitter memory error.
OUT CARD "e" transmitter connector card communication error.
CON CARD -F/An connector card communication error.
BLE COMM ERR BLE radio error.
AOUT ERR "e" transmitter analog output error.
CON BUS "e" transmitter probe serial memory communication error.
