3-O&M_Settings_r1r Section 3Page 34
EBTRON, Inc • 1663 Hwy 701 S., Loris, SC 29569 • Toll Free: 800-2EBTRON (232-8766) • Fax: 843-756-1828 • EBTRON.com
specified. The alarm can be configured to reset automatically or require manual reset when the alarm state
returns to “normal”. The alarm can be disabled when the airflow rate output is 0% (either measured or forced
to 0% by the low limit cutoff) to disable alarming when the system is in “off” or “unoccupied” modes.
3.12.3. Alarm Units of Measure [ALRM UM]
3.12.3.1. ALL PROBE TYPES EXCEPT THE -B PROBE TYPE CONFIGURED FOR PRESSURE
(DPCONVERT=YES)
The airflow units of measure used to activate the airflow alarm.
[Menu path: SETTINGS >↓ ALARM >↓ ALRM UM]
Default: FPM [m/s]
Optional Settings: CFM [L/s]
The area parameter(s) [AREA] of -F and -U and -B probe types must be entered (i.e. not equal to the
factory default value of {null}) for the LCD UM=CFM [L/s] option to be available. “ENTER AREA
<OK>” will be displayed when CFM [L/s] is selected. Press ENT or ESC to return to the “*ALRM
UM=FPM [L/s]” menu prompt.
3.12.3.2. -B PROBE TYPE CONFIGURED FOR PRESSURE (DPCONVERT=YES)
The pressure units of measure used to activate the pressure alarm.
[Menu path: SETTINGS >↓ ALARM >↓ ALRM UM]
Default: iWG [Pa]
Optional Settings: None
3.12.4. Alarm Setpoint [SETPNT]
The setpoint used to activate the airflow alarm.
[Menu path: SETTINGS >↓ ALARM >↓ SETPOINT]
3.12.4.1. ALL PROBE TYPES EXCEPT THE -B PROBE TYPE
3.12.4.1.1. ALRM UM = FPM [m/s]
Default: 0
Optional Settings: 0 to 999999 (FPM) [0.00 to 99.9 9 (m/s)]
3.12.4.1.2. ALRM UM = CFM [L/s]
Default: 0
Optional Settings: 0 to 999999 (CFM) [0.00 to 999999 (L/s)]
3.12.4.2. -B PROBE TYPE
The optional settings range is ± if DIRECTION=BI.
3.12.4.2.1. ALRM UM = FPM [m/s]
Default: 0
Optional Settings: 0 to 999999 (FPM) [0.00 to 99.99 (m/s)]
