ECD SmartDRY SD Series User Manual

SD Series Dry Cabinets Setup and Operation Manual | A62-3337-00 Rev: 1.0.0 Page 98
APPENDIX B: SPECIFICATIONS
3D-10
E62-3310-30/35
3D-10SB
E62-3310-60/65
3D-30
E62-3330-30/35
3D-30XD
E62-3339-30/35
Recovery*:
Suggest Interval of cabinet ac-
cess
12/hour 12/hour 12/hour 12/hour
Recovery to <5%
3 minutes 3 minutes 4 minutes 4 minutes
Recovery to set point from
opened door
3 minutes 3 minutes 4 minutes 9 minutes
* Recovery tested at 50%RH @ 25°C
Doors & Filiment Reel Racks:
Number of Doors
2
2
6
2
Magnetic Door Seals
Yes
Yes
Yes
Yes
ESD Safe
Yes
Yes
Yes
Yes
Number of Shelves
1 Floor Shelf
1 Floor Shelf
2 Floor Shelves
2 Floor Shelves
Adjustable Filiment Reel Racks
2
2
N/A
6
Additional Filiment Reel Racks
Available
Yes Yes Yes Yes
Max Load Capacity per Shelf
44 kg (100 lbs)
44 kg (100 lbs)
44 kg (100 lbs)
44 kg (100 lbs)
Casters
76.2 mm (3") diameter
76.2 mm (3") diameter
76.2 mm (3") diameter
76.2 mm (3") diameter
Weight & Dimensions:
External Dimension (HxWxD)
1143 mm x 508 mm x
762 mm
(45” x 20” x 30”)
1143 mm x 508 mm x
762 mm
(45” x 20” x 30”)
1778 mm x 1016 mm x
762 mm
(70” x 40” x 30”)
1778 mm x 1016 mm x
762 mm
(70” x 40” x 30”)
Internal Dimension (HxWxD)
985 mm x 479 mm x
540 mm
(38.8” x 18.8” x 21.2”)
985 mm x 479 mm x
540 mm
(38.8” x 18.8” x 21.2”)
1500 mm x 990 mm x
540 mm
(59” x 38.9” x 21.2”)
1500 mm x 990 mm x
540 mm
(59” x 38.9” x 21.2”)
Weight
< 70kg (155 lbs) < 70kg (155 lbs) < 163 kg (360 lbs) < 163 kg (360 lbs)
Internal Capacity
283 liters (10 cu ft) 283 liters (10 cu ft) 850 liters (30 cu ft) 850 liters (30 cu ft)
Construction:
Country of Manufacturing
USA
External & Internal
ESD powder coated steel
