SD Series Dry Cabinets Setup and Operation Manual | A62-3337-00 Rev: 1.0.0 Page 45
9.2 SMARTBAKE™ MENU (MODEL 3D-10SB ONLY)
The SmartBAKE™ process has two settable parameters: Temperature (30C to 60C) and time. To manually se-
lect the bake temperature and time, select Manual Bake.
ECD IS DEVELOPING A “SMART” PROCESS TO AUTOMATICALLY CALCULATE AND SET PA-RAME-
TERS FOR TEMPERATURE (30C TO 60C) AND TIME. CURRENTLY THIS FEATURE IS DISABLED. ONCE
AVAILABLE, IT CAN BE ACTIVATED WITH A FIRMWARE UPDATE.
To access the SmartBAKE™ Menu:
1) From the Main Display, enter the Main menu by pressing the Menu button. enter the SmartBAKE™
Menu by pressing the Bake button.
2) Select a desired menu item.
