Eclipse 500 User Manual

Section 7. Fuel Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
130 Version 2.0 April 2007
7.5.15 Fuel Balancing
Fuel can be fed from either wing to the opposite engine via the crossfeed valve.
When a fuel imbalance of 50 pounds between the wings is detected, the crossfeed
valve automatically opens, the electric fuel pump on the heavy side automatically
starts, and a FUEL AUTO XFEED L←R or FUEL AUTO XFEED L→R status
message appears.
Since the electric fuel pumps operate at a higher pressure than the ejector boost
pumps, fuel from the heavy wing will flow to both engines. When the quantity
difference is within 10 pounds, the crossfeed valve closes and the electric fuel pump
is switched off. The rate at which an imbalance is corrected depends on engine fuel
burn. Normally a lateral imbalance will be corrected within 10 minutes.
In the event of an engine failure, the automatic balance system keeps the fuel load
balanced while ensuring that the remaining usable fuel is available to the operating
engine.
If the auto crossfeed system is not automatically activated, fuel can be manually
balanced using the XFEED line select key on the fuel synoptic. Activating manual
fuel XFEED causes a FUEL MAN XFEED LÆR or FUEL MAN XFEED LÅR status
message to appear.

Eclipse 500 Specifications

General

Manufacturer	Eclipse Aerospace
Model	Eclipse 500
Type	Very Light Jet
Engines	2 × Pratt & Whitney Canada PW610F turbofans
Thrust per engine	900 lbf (4.0 kN)
Wingspan	37.9 ft (11.6 m)
Height	11.0 ft (3.4 m)
Avionics	Avio NG
First Flight	August 26, 2002
Maximum Speed	430 mph
Range	1, 125 nautical miles
Service Ceiling	41, 000 ft (12, 500 m)
Crew	1 or 2
Max Takeoff Weight	6, 000 pounds
Seating Capacity	4-6
Length	33 feet 6 inches
Empty Weight	3, 550 pounds
Payload	Varies with configuration and fuel load
