The environmental (ENVIR) synoptic provides control of cockpit and cabin
temperatures, as well as desired evaporator fan speeds through the concentric MFD
knobs. Control of DEFOG, DEHUMID and AIR COND is provided on this synoptic
through three line select keys. To set desired temperature, rotate the outer portion of
the concentric MFD knob to select the function to be controlled. (The blue box steps
through the four parameters.) Rotate the inner MFD knob to the desired setting.
Table 23. Environmental Synoptic Selections
Function Settings
84 F / 78 F Current cockpit and cabin temperature in degrees F
SET
Desired cockpit and cabin temperature in 2 degree increments from
64° F to 84° F plus MAX HEAT and MAX COOL. Default setting at
power-up is 72° F
FAN
Cockpit and cabin evaporator fan—OFF / AUTO / LOW / MEDIUM /
HIGH. Default setting at power-up is AUTO
DEFOG OFF / ON. Default setting at power-up is OFF
DEHUMID OFF / ON. Default setting at power-up is OFF
AIR COND OFF / AUTO. Default setting at power-up is OFF
OAT Outside Air Temperature in degrees °C
ECB LINK Selects Climate Control ECB synoptic page
