Eclipse 500 User Manual

Section 7. Fuel Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
124 Version 2.0 April 2007
7.5.8 Fuel Valves
CROSSFEED VALVE
The left and right sides of the fuel system are connected by a crossfeed valve, which
operates automatically to maintain fuel balance between the wings within 50 pounds.
The crossfeed valve requires electrical power to operate and is normally controlled by
the ACS, but can be overridden by initiating manual fuel crossfeed using the fuel
synoptic. A loss of electrical power will cause the crossfeed valve to close.
Commanded crossfeed valve position is displayed on the fuel synoptic. Should the
crossfeed valve fail or not reach its commanded position, a XFEED VLV FAIL
advisory message appears and fuel crossfeed may not be available.
FUEL SHUTOFF VALVES
An electric fuel shutoff valve for each engine is located in the wing root downstream
of the ejector boost pumps and electric fuel pumps. The valves open and close
automatically during normal engine start and shutdown sequence. They also close
when the associated FIRE-ARMED button is pressed. With a loss of electrical power
a fuel shutoff valve will not operate, a L (R) FUEL SOV FAIL advisory message
appears and the fuel shutoff valve will remain in its last commanded position.
7.5.9 Fuel Heat
A fuel/oil heat exchanger in each engine keeps fuel within normal operating
temperature limits.

Eclipse 500 Specifications

General

Manufacturer	Eclipse Aerospace
Model	Eclipse 500
Type	Very Light Jet
Engines	2 × Pratt & Whitney Canada PW610F turbofans
Thrust per engine	900 lbf (4.0 kN)
Wingspan	37.9 ft (11.6 m)
Height	11.0 ft (3.4 m)
Avionics	Avio NG
First Flight	August 26, 2002
Maximum Speed	430 mph
Range	1, 125 nautical miles
Service Ceiling	41, 000 ft (12, 500 m)
Crew	1 or 2
Max Takeoff Weight	6, 000 pounds
Seating Capacity	4-6
Length	33 feet 6 inches
Empty Weight	3, 550 pounds
Payload	Varies with configuration and fuel load
